Professional Pinball Board Repairs:

The Coin-Op Cauldron is an established coin-operated elecronic circuit board repair business. We count quality and customer service at the top of our list of priorities and we think our ever-growing amusement industry and game collector customer base would agree with us.
Our aim is to keep those cherished games of yours running well into the future. Founded by an ex-Atari engineer with 30 years electronics and software experience including coin-op, you know you're in good hands. All boards are fully repaired, tested and then play-tested. Every function of every board is checked which is why we have a less than 1% return rate. All boards are guaranteed for 90 days and shipped in static protective bags and brand new boxes.

How to determine your board repair price:

(Price list effective 3-1-22)

If your board has never been worked on before, is not burned, does not have missing components and is not physically damaged, then you can use the prices listed below to determine the actual repair price. The prices are ' fixed' meaning that you will not pay more than the listed price providing the above criteria has been met.

If your board does have some form of damage or previous repair then we need to perform a free evaluation to determine whether the repair price will be the same as the fixed price or more expensive before we can begin the repairs. We will notify you of the cost and you can then make a decision to proceed or not.

If in any doubt, please call us. Please note that our hours are Monday - Friday 9am to 5pm Eastern Standard Time.

"No Faults Found" boards:

If all the boards sent in for repair under one particular shipment are tested and found to be 'no faults found', the first board is charged at $35.00 and the remaining boards are $15.00 each. The $35.00 test fee also applies to single board shipments that are "no faults found".

Any boards tested and found to be ' no faults found' during a multi-board repair (with at least one full price repair) are charged at $15.00 per board.

How to send boards to us for repair:

In most cases it is best that you call and talk to us before sending in boards for repair but if not:

Place the board(s) in static protective bags. If you do not have static protective bags, wrap the boards in aluminium foil except for power supplies (remove any batteries on CPU boards).
Place the board(s) in a box that has at least 1 inch of good packing all around ( packing peanuts etc.). Do not use polystyrene sheet foam!
Remember to include a cover letter giving your return address, e-mail and telephone number.

Payment options:

A check or money order with the board(s).
Payment through Paypal after repair (we will notify you through e-mail). An additional 2 % fee applies.

Shipping Rates (return shipping):

We return ship all boards via Fedex Ground, UPS (preffered) or the US Postal Service but can accomodate other shipping methods if required. Rates are as follows for a single board. Please contact us for revised pricing if you are sending multiple boards for repair:

Boards up to 12" x 10" x 1.5"	$15.50
Boards up to 13" x 11.25" x 2.25"	$17.00
Boards up to 17.5" x 12.25"x 3"	$19.00

Credit Terms

Credit terms are available for established businesses. Write or e-mail for details.

The Coin-Op Cauldron
103 Armistead lane
Easley, SC 29642

Telephone: (864) 238 1707

Contact Us


Part #	Description	Repair	Notes
`PCA-009`	`CPU/Driver board combo`	`$125.00`
`PCA-020`	`Dot matrix display controller`	`$88.00`
`PCA-007`	`Flasher relay board`	`$30.00`
`PCA-008`	`Sound board`	`$88.00`
`PCA-019A`	`Power supply`	`$68.00`


* Please note that as of February 2007, we will no longer be repairing Bally CPU boards with corrosion damage or any previous non-professional repair work.

Part #	Description	Repair	Notes
`AS-2518-14`	`Lamp driver`	`$44.00`
`AS-2518-16`	`Solenoid driver board`	`$88.00`
`AS-2518-17`	`CPU board*`	`$125.00`	`No corrosion`
`AS-2518-22`	`Solenoid driver board`	`$88.00`
`AS-2518-23`	`Lamp driver board`	`$44.00`
`AS-2518-32`	`Sound board`	`$68.00`
`AS-2518-35`	`CPU board*`	`$125.00`	No corrosion
`AS-2518-50`	`Sound board`	`$68.00`
`AS-2518-51`	`Sound board`	`$68.00`
`AS-2518-54`	`Rectifier board`	`$50.00`
`AS-2518-61`	`Squawk and Talk Sound`	`$78.00`
`AS-2518-62`	`CPU board*`	`$125.00`	No corrosion
`-`	`6802 CPU board*`	`$125.00`	`Pre 6803 system`
`-`	`Interfacer board`	`$84.00`	`Pre 6803 system`
`AS-2518-73`	`Power Module board`	`$50.00`
`AS-2518-131`	`CPU board*`	`$125.00`	No corrosion
`AS-2888-3`	`Sound Board`	`$68.00`
`AS-3022-2`	`Sound board`	`$68.00`
`AS-3022-6`	`Sound board`	`$68.00`
`A084-91864`	`Sounds Deluxe board`	`$78.00`
`A084-91785`	`6803 Power Supply`	`$78.00`
`A084-91786`	`6803 CPU/driver board`	`$125.00`
`-`	`6803 14 char. display`	`$74.00`	`Electronics only`
`AS-2518-15`	`6-Digit display`	`$45.00`	`Glass extra`
`AS-2518-58`	`7-Digit display`	`$45.00`	`Glass extra`
`AS-2518-21`	`Credit/Ball-in-play display`	`$35.00`	`Glass extra`
`AS-2518-56`	`Sounds plus board`	`$78.00`
`AS-2518-57`	`Vocalizer sound module`	`At cost`
`AS-2518-52`	`Auxillary lamp driver board`	`$38.00`
`C-13286`	`Sound lamp overlay board`	`$40.00`	`Game Show`
`AS-2518-18`	`Rectifier board`	`$48.00`


Part #	Description	Repair	Notes
`A0015204`	`Power board`	`$88.00`
`A0015205`	`Power board`	`$88.00`
`A0015301`	`Switch board`	`$40.00`
`A001540x`	`68K CPU board`	`Call`	`Limited repair, please call`
`A0017703`	`Power Driver board`	`$88.00`
`A0017704`	`Driver board`	`$88.00`
`A0021701`	`Sound Board`	`$88.00`


Part #	Description	Repair	Notes
`520-5000-0x`	`Power Supply`	`$68.00`
`520-5047-0x`	`Power supply`	`$68.00`
`520-5002-0x`	`Sound board`	`$88.00`
`520-5050-0x`	`Sound board`	`$88.00`
`520-5077-0x`	`Sound board`	`$88.00`
`520-5126-0x`	`Sound board`	`$88.00`
`520-5055-0x`	`Dot Disp.ontroller`	`$78.00`
`520-5015-0x`	`MRB board`	`$38.00`
`520-5021-0x`	`PPB Board`	`$38.00`
`520-5003-0x`	`CPU board`	`$125.00`
`DE-0288-1A`	`Sound board`	`$88.00`	`Laser War (early board)`
`237-0139-00`	`DMD Controller`	`$98.00`	`Maverick, Frankenstein etc.`


*Part #*	*Description*	*Repair*	*Notes*
`20-10004C`	`MPU-1 CPU board`	`At cost`
`20-10016`	`MPU-2 CPU board`	`At cost`
`20-10003B`	`LDU-1 Lamp driver board`	`$40.00`
`20-10012C`	`LDU-2 Lamp driver board`	`$40.00`
`20-1008A`	`SSU-1 Sound board`	`$78.00`
`20-10055`	`MSU-1 Sound board`	`$78.00`
`20-10010B`	`DDU-2 Dual display board`	`$38.00`
`20-10009A`	`BDU-1 Display board`	`$38.00`
`20-100064`	`BDU-2 Display board`	`$38.00`
`20-10002B`	`SDU-1 Solenoid driver board`	`$48.00`


Part #	Description	Repair	Notes
`-`	`System 1 CPU board`		`No repair`
`-`	`System 1 Power supply`		`No repair`
`-`	`System 1 Driver board`		`No repair`
`PB03-D102-001`	`System 80 CPU board`	`$125.00`	`Dual PROM version`
`PB03-D107-001`	`System 80 CPU board`	`$125.00`	`Single EPROM ver. 1`
`PB03-D107-003`	`System 80 CPU board`	`$125.00`	`Single EPROM ver. 2`
`D20869`	`System 80A CPU board`	`$125.00`
`D20869`	`System 80B CPU board`	`$125.00`
`-`	`System 80 Sound/Speech`	`$78.00`	`Excl. SC01 Speech IC`
`-`	`System 80 Power supply`	`$54.00`
`-`	`System 80 Sound board`	`$68.00`	`Limited repair, call`
`-`	`System 80B Sound board`	`$88.00`
`-`	`System 80B 2x 20 display`	`Call`	`Limited repair, call`
`-`	`S80 Driver boards (all)`	`$58.00`
`-`	`System 3 CPU board`	`$125.00`
`-`	`System 3 driver board`	`$68.00`
`-`	`System 3 sound board`	`$78.00`
`-`	`System 3 Aux. sound board`	`Call`	`Limited repair, call`
`-`	`System 3 Display controller`	`$78.00`
`-`	`System 3 A/N 2x 20 display`	`$78.00`	`Electronics only`
`-`	`System 3 Aux. power board`	`$40.00`
`-`	`Aux. lamp driver chase board`	`$40.00`	`Haunted House etc.`
`MA-1293`	`3-Transistor driver board`	`$45.00`
	`Pop-bumper driver board`	`$40.00`
`MA-1294`	`Aux. sound board (Yamaha FM)`	`$45.00`


Please note that as of February 2007, we will no longer be repairing Stern CPU boards with corrosion damage or previous non-professional repair work.

Part #	Description	Repair	Notes
`MPU-100`	`CPU board`	`$125.00`	`No corrosion`
`MPU-200`	`CPU board`	`$125.00`	`No corrosion`
`SDU-100`	`Solenoid/Driver board`	`$88.00`
`LDA-100`	`Lamp Driver board`	`$44.00`
`VSU-100`	`Speech board`	`$58.00`	`Excl. Speech CPU`
`SB-100`	`Sound board`	`$78.00`
`SB-300`	`Sound board`	`$78.00`


Part #	Description	Repair	Notes
`520-5136-42`	`Whitestar CPU/Sound board`	`$125.00`
`520-5137-01`	`I/O Power Driver board`	`$88.00`
`520-5138-00`	`Display Power Supply board`	`$42.00`
`237-0139-00`	`192x64 (Big) display controller`	`$88.00`


Part #	Description	Repair	Notes
`-`	`System 3 CPU`	`$125.00`
`-`	`System 4 CPU`	`$125.00`
`-`	`System 6 and 6A CPU`	`$125.00`
`-`	`System 7 CPU`	`$125.00`
`1C-2001-146`	`Sound Board`	`$78.00`
`-`	`System 3-7 Driver Board`	`$88.00`
`-`	`System 3-9 Power Supply`	`$68.00`
`D-10535`	`System 9 CPU Board`	`$150.00`
`-`	`System 11 CPU Board (all versions)`	`$150.00`
`D-8345`	`System 11 Power supply`	`$68.00`
`D-12246`	`System 11 Power supply`	`$68.00`
`D-12247`	`System 11 Aux. Driver board`	`$48.00`
`D-11197`	`System 11 Background Music board`	`$68.00`
`D-11298`	`System 11 Background Music board`	`$68.00`
`D-11581`	`Sys.11 B'ground Sound & Speech board`	`$68.00`
`C-11030`	`System 11 Background sound board`	`$68.00`
`D-12338`	`System 11 Background Sound board`	`$68.00`
`A-12742`	`WPC CPU board`	`$78.00`	`ASIC no incl.`
`A-17651`	`WPC-S CPU board`	`$78.00`	`PIC not included`
`A-21377`	`WPC-95 CPU board`	`$78.00`	`PIC not included`
`A-20516`	`WPC-95 Audio/Visual board`	`$135.00`	`ASIC not incl.`
`-`	`WPC Power Driver board (all versions)`	`$88.00`
`A-12738`	`WPC-89 Sound (pre DCS)`	`$88.00`
`A-16917`	`DCS Sound board`	`$125.00`
`A-15028`	`Fliptronic I (Addams Family) board`	`$48.00`
`A-15472`	`Fliptronic II board`	`$48.00`
`A-14039`	`WPC Dot Controller`	`$50.00`
`04-12329`	`Pinball 2000 Driver Board`		`No repair`
`-`	`Trough Opto boards (all new parts)`	`$38.00`
`A-20909`	`48-Lamp driver board`	`$48.00`	`Safe Cracker`
`A-16807`	`10-Opto switch driver board`	`$38.00`	`TZ + others`
`A-18151`	`10-Opto switch driver board`	`$38.00`
`A-15646-2`	`'The Shadow' 24-Opto driver board`	`$40.00`	`Battlefield`
`A-16120`	`DC Motor controller board`	`$45.00`
`A-16998`	`16-Opto switch driver board`	`$40.00`	`STTNG + others`
`A-16100`	`8-Driver auxillary driver board`	`$35.00`	`STTNG, TZ etc.`
`A-20669`	`Strobe lamp driver board`	`$48.00`	`Attack from Mars`
`A-15189`	`Accelerator (Supercharger) controller`	`$78.00`	`The Getaway`
`A-13088-x`	`Triac driver board`	`$38.00`
`A-15139`	`High current/power driver (3 channel)`	`$45.00`	`Addams Family`
`A-14977`	`7-Opto switch driver board`	`$35.00`
	`Sys 11 Backbox Interconnect board`	`$35.00`
`C-13287`	`Sound overlay board`	`$48.00`	`Whirlwind`
`A-15680`	`Bidirectional motor driver board`	`$40.00`	`Doctor Who`
`A-15500`	`5-opto switch bank (electronics only)`	`$50.00`	`Doctor Who`
`C-13286`	`Sound lamp overlay board`	`$48.00`	`Game Show`
`C-13892`	`Triac driver board`	`$35.00`	`Doctor Dude`
